CDL Zov -} theem twj

Name: Tuam Tshoj CDL Zov Ntau - theem twj ua lag luam- Customized cdl multi}} theem twj ua nyob hauv Suav teb
Brand: Jovidia
SKU: 286505365

Cov khoom lag luam piav qhia txog CDL multi -}}}}}}}}}}}}}}}}}}}}}}}}}}}}}} theem unentrifugal twj tso kua mis. Lawv tshwj xeeb qauv cov motors ntsug thiab ceev-} Installet tshuab cov ntsaws ruaj ruaj ...

Xa kev nug

Hauj lwm lawm

Cov khoom lag luam

CDL multi - theem twj CDL / CTE}}}}}}}}}}}}}}}}}}}}}}}}}}}}} theem unentrifugal twj tso kua mis. Lawv muaj cov qauv kev ntsuas ntsug thiab nrawm-} Installation Feals, nrog rau qhov optimized tshuab foob qauv qauv. Lawv txais yuav cov tshiab ib - cov qauv sib hloov, muaj peev xwm thauj ntau yam los ntawm cov kais dej rau cov kua dej. Lawv haum rau qhov kub thiab txias nrog qhov kub thiab txias thiab siab li siv tau, thiab tseem siv tau rau kev hloov kua ntau, nrog kev ua haujlwm yooj yim.

Khoom nta

CDL Zov -} theem twj

Los ntawm kev kawm zoo hydraulic qauv thiab kev ua haujlwm siab tsim tau, kev ua haujlwm thiab kev pabcuam lub neej ntawm lub twj tso kua mis tau txhim kho.
Vim kev siv cov ntsaws ruaj ruaj nrog cov ntaub ntawv ntawm cov ntaub qhwv tawv thiab cov fluororubber rau lub taub dej thiab kub ntawm lub nruab nrab ntawm nruab nrab tuaj yeem txhim kho.
Cov txheej txheem tag nrho yog kev cog lus, qhov loj me, qhov hnyav yog lub teeb, lub zog tsis muaj txiaj ntsig zoo kawg li yog qhov zoo tshaj plaws, thiab kev saib xyuas yooj yim.
Cov inlet thiab qhov hluav taws xob ntawm mult - theem twj tso nyob ntawm tib lub hauv paus, thiab tuaj yeem siv ncaj qha rau hauv pipelines.
Siv cov qauv motors, cov neeg siv tuaj yeem hloov kho cov motors raws li lawv cov kev xav tau. Cov neeg siv tau tuaj yeem muab cov khoom siv ntse tsim nyog raws li xav tau kom muaj txiaj ntsig tiv thaiv cov twj tso kua mis xws li qhuav khiav, theem uas ploj lawm, thiab dhau lawm.

Cov khoom tsis muaj

Tus Qauv Qauv	Nruab nrog lub cev muaj zog (Kw)	Q (m³/n)	30	40	50	60	64	70	80
CDL64-10-1	4.0	H (m)	19	18	16	14	13	11	8
CDL64-10	5.5		27	25	23	21	20	18	15
CDL64-20-2	7.5		39	36	33	29	27	23	17
CDL64-20-1	11		46	44	40	36	34	30	24
CDL64-20	11		53	51	47	43	41	37	30
CDL64-30-2	15		66	62	56	50	47	41	32
CDL64-30-1	15		73	69	63	57	54	48	39
CDL64-30	18.5		80	76	70	64	61	55	46
Cdl64-40-2	18.5		92	87	80	71	67	60	47
CDL64-40-1	22		100	94	87	78	74	67	54
Cdl64-40	22		107	101	94	85	81	74	61
CDL64-50-2	26		121	114	105	95	89	80	64
CDL64-50-1	26		128	121	112	102	96	87	71
Cdl64-50	30		136	129	119	109	103	94	78
CDL64-60-2	30		150	142	131	118	111	101	81
CDL64-60-1	37		157	149	138	125	118	108	88
CDL64-60	37		164	156	145	132	125	115	95
CDL64-70-2	37		179	169	156	141	133	121	99
CDL64-70-1	37		186	176	163	148	141	128	106
Cdl64-70	45		193	183	170	155	148	135	112
Cdl64-80-2	45		207	196	182	164	156	142	116
CDL64-80-1	45		215	203	189	171	163	149	123

Cov tau txais daim ntawv thov

Ib qho nyias nyias, huv si, tsis - flammable thiab tsis yog - qhov nruab nrab tsis muaj cov khoom tawg lossis cov fibers.
Xws li cov dej ntxhia dej, dej ntshiab, cov dej ntshiab, cov roj ua kom zoo thiab lwm yam hluav taws xob siv tshuaj.
Cov khoom siv tseem ceeb ntawm cov twj tso kua mis yog stainless hlau, thiab nws tuaj yeem siv rau twj tso tawm me me corrosive media.

Kev xa dej: Pom kev dej ntawm cov dej dej, cov dej tsis muaj dej los ntawm kev cog axip, koob rau lub siab}}}}} Rose vaj tse.
Kev txhawb zog: Txheej txheem dej system, tu cev, siab {}} kub tawm system, hluav taws kub tiv thaiv.
Kev lag luam ua kua: Cua txias thiab cua txias thiab cov dej txias thiab cov hws, tshuab ntaus, acid thiab alkali.
Dej kho: Ultrafiltration System, Rov qab osmosis system, system distillation, separator, pas dej da.
Irrigation: Kev ywg dej ua teb, sprinkler Irrigation, txia Irrigation.

Ua Haujlwm Cov Ntsiab Cai

Thaum lub cev muaj zog tsav cov impeller ntawm tus pas kom nrawm nrawm, cov kua uas muaj rau ntawm lub zog ntawm cov hniav ntws ntawm lub periphery ntawm tus impeller. Vim muaj cov nyhuv ntawm cov hniav, lub siab thiab nrawm ntawm cov kua ua rau ib txhij. Cov kua ntws los ntawm cov ntws raws ntawm lub plhaub thiab yog qhia rau qhov tom ntej- theem theem cuam. Nyob rau hauv txoj kev no, nws kis los ntawm txhua tus impellers thiab taw qhia shells ua tiav, ntxiv lub zog lub zog ntawm cov kua. Tom qab txhua tus impeller tau sib xyaw ua ke, qee lub taub hau tau txais.
CDL multi -} theem ntsug centrifugal twj tso kua mis yog ib qho tseem tshiab ntawm cov twj tso kua mis los ntawm 1990s. Nws cov txiaj ntsig loj suav nrog kev txuag hluav taws xob, kev ua haujlwm yooj yim, thiab kev siv lub ntsej muag zoo nkauj, thiab kev siv tau ruaj khov, ua haujlwm nyob rau hauv tsis muaj xau thiab lub neej kev pabcuam ntev. Lub zog ua axial tau daws los ntawm cov pob tawb sib npaug, ua haujlwm khov kho, thiab lub suab nrov qis, thiab nws cov kev teeb tsa tseem zoo dua li cov khoom muaj sia. Nws tuaj yeem muab tau yooj yim hauv txhua txoj haujlwm nruab nrab ntawm kab rov tav pipeline.
CDL multi -} theem ntsug centrifugal twj tso kua mis muaj siab high high high. Cov inlet thiab offlet diameters ntau ntawm 25 txog 100 millimeters. Tus nqi txaus yog 2 txog 72 tons ib teev, thiab lub taub hau yog 25 txog 150 meters. Muaj 9 koob thiab ntau dua 70 cov lus qhia hauv tag nrho. Nws tuaj yeem ua kom tau raws li cov dej thiab dej ntws tawm thiab ua kom zoo li hluav taws kev tiv thaiv kev xav tau ntawm high-}}} rise build mines. Nws yog cov khoom nqus zoo tshaj plaws rau kev thauj cov dej txias thiab dej kub lossis dav dav, thiab kua nrog cov khoom siv lub cev thiab tshuaj lom neeg nyob hauv ntau yam kev lag luam.
